Veterinary ultrasound medical products are based on ultrasound technology, utilizing the propagation and reflection characteristics of high-frequency sound waves in animal bodies to achieve imaging and diagnosis of animal tissues and organs.Through the interaction between ultrasound and tissue, detailed anatomical structure images and blood flow velocity data can be obtained. In addition to monitoring pregnancy, it can also perform abdominal organs examination of animals, detect basic diseases and follicle development, etc. This has greatly improved reproductive management for veterinarians, allowing for more accurate diagnoses and improved breeding programs.Konted's research in the Doppler field has supplemented and improved the accuracy and specificity of echocardiography, and in some cases, abnormal blood flow patterns can be detected before significant anatomical damage occurs.
Handheld ultrasound is providing convenience for doctors. Multifunctional ultrasound can meet doctors' needs for ultrasonic scanning of various parts of the body. Konted designed C10T single probe multi-functional ultrasound sensor and C10RL dual probe multi-functional ultrasound sensor for doctors. C10T is a curved probe(convex probe+linear probe+ cardiac preset 3 in 1 probe), C10RL is a probe with a convex array at one end and a linear array at the other end. They can all scan abdominal organs, superficial parts, and basic cardiac examinations.
Model | C10T | C10RL |
Photo Reference | ||
Scanning system | Convex+Linear+Cardiac | Convex+Linear+Cardiac |
Transducer | Single head | Dual head |
Radius | Convex:R45 | Convex: R45 |
Footprint | Linear: L45 | Linear: L25 |
Frequency | 2.5/3.5Mhz 3.5/5Mhz 7.5/10Mhz | 2.5/3.5Mhz 3.5/5Mhz 7.5/10Mhz |
Depth | 90-160mm 90-305mm 20-80mm | 90-160mm 90-305mm 20-100mm |
Elements | 128 | 128 |
Application | Abdomen Obstetrics / Gynecology Cardiac Kidney Urology Breast Thyroid MSK Vascular Pediatrics Carotid Small Parts | Abdomen Obstetrics / Gynecology Cardiac Kidney Urology Breast Thyroid MSK Vascular Pediatrics Carotid Small Parts |
Connection | Wifi | Wifi & USB |
Display mode | B,B/M,Color Doppler, PW, Power Doppler | B,B/M,Color Doppler, PW, Power Doppler |
Battery Capacity | 4200mAh | 2800mAh |
Charging method | Wireless charging/ Micro USB cable | Wireless charging/Type-C cable |
Battery Replaceable | Yes | Yes(engineer) |
Battery last | 3-4 hours(working time), More than 12 hours(stand by time) | 3 hours(working time), Supporting work while charging |
Size | 156mm×70mm×30mm | 125(h)x70(w)x20(d) mm |
Weight | 227g | 90g |
Gross Weight | 1.1kg | 0.8kg |
Packing size | 240*235*100mm | 185(h)x105(w)x55(d) mm |
SOFTWARE CONTROLS | GN(gain) D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Mode B,B/M,Color Doppler,PW,Power Doppler Biopsy Page Left/Right Up/Down 8TGC | GN(gain) D(depth) ENH(enhancement) DR(dynamic range) F(frequency) PRF WF Focus Mode B,B/M,Color Doppler,PW,Power Doppler Biopsy Page Left/Right Up/Down 8TGC |
