Konted's latest pet ultrasound series probes are designed specifically for the veterinary industry. If your pet has diseases in the kidneys, bones, blood vessels, lungs, and nerves, you can choose to purchase the C10 (Veterinary Series). Convex array and linear array probes can be selected according to different conditions such as prostate disease, heart disease, kidney disease, etc.
Product specs:
| Probe | Wireless dual head convex+linear probe(C10RL) | Wireless Convex probe（C10UR） | Wireless Convex probe（C10UL） |
| Elements | Dual 128 | 128 | 128 |
| Frequency | 3.5/5.0mhz, 7.5/10mhz,2.5/5.0mhz | 3.5/5.0mhz | 7.5-10Mhz |
| Depth | 90-305mm, 20-100mm, 90-160mm | 90-305mm | 40-100mm |
| Preset 16+ | Abdomen, GYN, OB, Cardiac, Urology, Kidney, Lung, User1, User2 | Abdomen,Urology，Kidney, Lung, User1, User2,Pet organs | Thyroid, Small parts, pediatrics, Vascular, Carotid, Breast, Msk, Nerve, User1, User2,Pet organs |
| Host | Tablet, Smart phone, PC | Tablet, Smart phone, PC | Tablet, Smart phone, PC |
| Connection | WiFi&USB | WiFi&USB | WiFi&USB |
| Software Adjustable Parameters | GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency),FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down. | GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote | GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote |
| Measurement | B: Length, Area/Circumference, Angle, Trace, Distance GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL) | B: Length, Area, Circumference, GA(CRL, BPD, GS, FL, HC, AC) B+M: Heart rate, Time, Distance B+PW:Velocity,Heart rate(2), S/D, Depth | B: Length, Area, Circumference, GA(CRL, BPD, GS, FL, HC, AC) B+M: Heart rate, Time, Distance B+PW:Velocity,Heart rate(2), S/D, Depth |
| Playback Frames | 100, 200, 500, 1000 optional | 100, 200, 500, 1000 optional | 100, 200, 500, 1000 optional |
| Display Mode | B, B+B, B/M, Color, PW, PDI, B+Color+PW | B, B/M,Color,PW,PDI | B, B/M,Color,PW,PDI |
| Image Gray Scale | 256 level | 256 level | 256 level |
| WiFi Type | Built-in WiFi, 802.11g/20MHz/2.4G/5G/450Mbps | Built-in WiFi, 802.11g/20MHz/5G/450Mbps | Built-in WiFi, 802.11g/20MHz/5G/450Mbps |
| Channel | 64 | 64 | 64 |
| Frame | 24f/s | 24f/s | 24f/s |
| Gain | 40-110Db | 40-110Db | 40-110Db |
| Language | Chinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil) | Chinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil) | Chinese, Ukrainian, German, English, Russian, France, Italian, Spanish, Portuguese (Brazil) |
| Power | by built-in Lithium battery | by built-in 1350mAh battery | by built-in 1350mAh battery |
| Battery Replaceable | Yes (by engineer) | Yes (by engineer) | Yes (by engineer) |
| Battery Last | 3hours (Working time), 12 hours(Stand by time) | 2hours (Working time), 12hours (Stand by time) | 2hours (Working time), 12hours (Stand by time) |
| Charger | USB Charger, wireless charger | USB charger | USB charger |
| Waterproof Grade | IPX5 | IPX5 | IPX5 |
